HDI FLEXO 1200

CRON HDI-1200is the first choice for packaging and folding carton printers and trade shops.

CRON HDI-1200 has a unique integrated platform that can automatically load and unload plates, effectively minimizing the chance of damage and avoiding potential waste when manually loading plates. As a result, the CRON HDI-1200 is very efficient and production costs are reduced.

Regardless of plate size, no need to mask the drum to seal vacuum holes when using CRON's unique patented leak-proof drum vacuum system.

Model

HDI-1200S

HDI-1200S+

HDI-1200H

HDI-1200H+

Max size
Min size

1000 × 1200mm (39 × 47 in)
200 × 200mm (7.9 × 7.9 in)

Plate loading

Manual mounting, Auto loading

Resolution

4000 dpi or 4800/5080 dpi

4000/8000 dpi or 4800/5080/9600 dpi

# S series speed

1.0~2.4 m2/h (4.5~2.0J/cm2) 4800/5080 dpi

# S+ series speed

1.0~2.4 m2/h (4.5~2.0J/cm2) 4800/5080 dpi
1.0~1.6 m2/h (4.5~2.0J/cm2) 9600 dpi

# H series speed

2.0~4.6 m2/h (4.5~2.0J/cm2) 4800/5080 dpi
1.6~2.4 m2/h (4.5~2.0J/cm2) 9600 dpi

# H+ series speed

3.8~4.6 m2/h (4.5~2.0J/cm2) 4800/5080 dpi
2.84 m2/h (4.5~2.0J/cm2) 9600 dpi

Plate type

Digital flexo plate, Letterpress, Ablative film

Plate thickness

0.11mm ~ 3.94mm

Net weight

1480 kg

Power supply

Single phase 220V ± 5% 50/60Hz

Rated Power

6KW

Dimension

2315×1150×1175 mm (W×L×H)

Environment

18~28℃; RH: 40%~60%

# The speed data in this sheet is for the Max. size.HDI-1600 series' maximum peripheral length is 1200mm
CRON reserves the rights to modify or change the design and technical parameters without notifying in advance.

Specifications Brochure
